$ 649.00
Discontinued/replaced by AF4515T5   The AM4515T5 Edge series handheld microscope features a high magnification of 500x - 550x, improved optics for sharper images, and Automatic Magnification Reading (AMR) for easy...
Availability: Out Of Stock
Sku: AM4515T5

Discontinued/replaced by AF4515T5



The AM4515T5 Edge series handheld microscope features a high magnification of 500x - 550x, improved optics for sharper images, and Automatic Magnification Reading (AMR) for easy measurement. This model also features a slightly extended working distance compared to previous Dino-Lite models with high magnification (9.5mm / 0.37" for 500x), which provides some clearance between the microscope lens and the object under view. Using the included software the AM4515T5 can detect and display the magnification, and store it with the captured picture automatically, making it especially useful for applications when reading the magnification is not feasible or difficult. AMR increases accuracy by eliminating the process of visually reading the magnification while keeping the possibility to be additionally calibrated in the included software. LED Control gives you command of the LED on/off toggle options.


Measurement Yes
Flexible LED Control No
Automatic Magnification Reading Yes
Extended Depth of Field No
Enhanced Dynamic Range No
Magnification Lock Yes
Body Material ABS Plastic
Microtouch Sensor Yes
LEDs White (8)
Polarization No
Magnification Range 500x - 550x
Working Distance Standard
Lens Type Glass
Megapixels 1.3 MP
Image Save Formats (Windows) BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Image Save Formats (Mac OS) JPEG, PNG
Operating System Windows XP, Vista, 7, 8, 10, Mac OS 10.9+
Connection Type USB 2.0
Included Software DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Imaging Standards UVC
Sensor Type CMOS
Resolution 1280 × 1024 pixels
Frame Rate (max) 30 FPS
Dimensions 10.5cm (L) x 3.2cm (D) (4.13" x 1.26")
Weight 105g (3.7 oz)
Cable Length 182cm (71.65 in)
Package Includes Microscope, Carry Pouch, Software CD, Edge Calibration Target, Alternate end caps
Warranty Period 2 years
Manufactured in Taiwan
Service & Support U.S. (www.dinolite.us) English & Spanish
Regulatory Approval CE, FCC


Shipping & Delivery

Orders placed before 3:00 P.M. Pacific Time, generally ship on the same day. Orders placed after the daily deadline will ship the following business day. Unless a UPS or FedEx shipping account is provided, the shipping courier (UPS, FedEx, USPS) used for your order may vary at our discretion.

To use your own shipping account, please add this Special shipping option to your cart. You must specify your desired shipping method and Account number in the "Order Notes" section of your shopping cart.

International Orders

The recipient is responsible for any and all duties, taxes, and other customs charges assessed by the importing country.

Warranty & Guarantee

Dino-Lite Microscopes include a 2-Year Warranty. Accessories include a 1-Year Warranty.

We offer a 30-day return/exchange period to ensure the product you select is the right fit for your application. Returns or exchanges within 30 days of purchase are offered no-questions-asked, simply contact us and we'll be glad to help you sort it out.
