$ 489.00
The AD4113TL Dino-Lite Pro is an “Enhanced working distance” model with an interchangeable nozzle feature that come with both a standard open faced nozzle as well as a sealed transparent...
Availability: 5 In Stock
Sku: AD4113TL

The AD4113TL Dino-Lite Pro is an “Enhanced working distance” model with an interchangeable nozzle feature that come with both a standard open faced nozzle as well as a sealed transparent cap nozzle designed to protect the lens and built in LED lights from dust, debris and moisture common to certain work environments. The removable nozzles also provide the user the option of increasing working distance when using the digital microscope without any nozzle installed. The AD4113TL is designed with greater working distance(s) in mind, also have enhanced lighting for improved illumination. The removable and interchangeable nozzle also allows the “AD” series of scopes to be receptive and compatible with current and future add-on feature upgrades, such as the 90 degree viewing option.

This model uses the H11 housing which is the second generation housing for the Dino-Lite that incorporates: improved magnification dial movement for smooth and easy adjustment and focusing with the Dino-Lite, a scroll lock feature for assuring desired set magnification/focus, and a cable strain relief (SR) that holds the Dino-Lite and its USB Cable together for greater resistance from pulls and twists.

The 1.3MP resolution AD4113TL is also equipped with calibrated measurement and other standard features such as “MicroTouch” shutter trigger, 8 built in LED lights with on/off, etc. found in previous AM4XX models. Dino-Lite digital microscopes are an affordable feature loaded portable magnification device designed for dedicated workstation, quality assurance, educational and general inspection applications. Included with each Dino-Lite digital microscope is a copy of the "DinoCapture 2.0" software, enabling you to "capture" either a photograph, video or time-lapsed video and perform measurement and other critical tasks.


Measurement Yes
Automatic Magnification Reading No
Extended Depth of Field No
Enhanced Dynamic Range No
Magnification Lock Yes
Body Material ABS Plastic
Microtouch Sensor Yes
LEDs White (8)
Polarization No
Magnification Range 10x - 90x
Working Distance Long
Lens Type Glass
Megapixels 1.3 MP
Image Save Formats (Windows) BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Image Save Formats (Mac OS) JPEG, PNG
Operating System Windows XP, Vista, 7, 8, 10, Mac OS 10.5+
Connection Type USB 2.0
Included Software DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Imaging Standards DirectShow, UVC
Sensor Type CMOS
Resolution 1280 × 1024 pixels
Frame Rate (max) 30 FPS
Dimensions 10.5cm (L) x 3.2cm (D) (4.13" x 1.26")
Weight 105g (3.7 oz)
Cable Length 182cm (71.65 in)
Package Includes Microscope, Carry Pouch, Software CD, Standard Calibration Target, Open Cap, Sealed Cap
Warranty Period 2 years
Manufactured in Taiwan
Service & Support U.S. (www.dinolite.us) English & Spanish
Regulatory Approval CE, FCC
